FCH3256-01 Smart Powerhouse Controller
The Fidar Electronics FCH3256-01 smart powerhouse controller runs two boilers and two pumps, cuts energy use by 30–40 %, links to the cloud over Ethernet and reports faults by SMS.
Runs two boilers and two pumps with lead–lag rotation
Sets temperature from outdoor conditions and real demand
Five sensors: collector flow/return, hot-water flow/return, ambient
Daily, weekly and monthly scheduling with the Persian calendar and holidays
Ethernet link to the cloud plus a built-in web server
Plant faults reported by SMS
Two-way Modbus gateway and a 1200 m sensor bus
User access levels with daily, monthly and annual reports
The FCH3256-01 puts a central heating plant under intelligent control: it sets plant temperature from the outdoor temperature and the building's actual demand, rotates boilers and pumps lead–lag, and by cutting the number of start–stop cycles takes 30–40 % off fuel use while extending equipment life. Five temperature sensors — collector flow and return, hot-water flow and return, and ambient — give it the real state of the system, and the operator reaches every setting and report from the 3.5-inch touch screen, the local network or the fidarcloud server.
Key features
- Runs two boilers and two pumps with lead–lag rotation
- Sets temperature from outdoor conditions and real demand
- Five sensors: collector flow/return, hot-water flow/return, ambient
- Daily, weekly and monthly scheduling with the Persian calendar and holidays
- Ethernet link to the cloud plus a built-in web server
- Plant faults reported by SMS
- Two-way Modbus gateway and a 1200 m sensor bus
- User access levels with daily, monthly and annual reports
Where it is used
- Plant rooms in residential and office towers
- Central heating in schools, offices and public buildings
- Hospitals and clinics that need stable hot-water temperature
- Hotels with pronounced peak-demand patterns
- Central monitoring of many plant rooms across one organisation
- Energy-optimisation projects targeting fuel cost
Installation
Mount the controller in the plant room beside the electrical panel, fit the sensors on the collector flow and return, the hot-water line and outdoors, and wire the relay outputs to the boiler and pump contactors.
